Programmed 2012-2014 Silverado 2500 BCM 22737275 Body Control Module

If you’re dealing with bizarre electrical gremlins in your GM truck or SUV, you’ve come to the right place. As a technician with over two decades of experience, I’ve seen firsthand how a failing Body Control Module (BCM) can turn a reliable workhorse into a source of constant frustration. Flickering lights, malfunctioning power windows and locks, a security system that won’t cooperate, or a persistent battery drain are all classic signs. This isn’t just an annoyance; it’s a critical failure in your vehicle’s central nervous system for body electronics.

This is the definitive, hassle-free solution. We offer a genuine OEM Body Control Module, part number 22737275 (also fits 22846365 and 22846364), that arrives at your door fully programmed to your vehicle’s specific VIN. Just provide us with your VIN after purchase, and our experts will flash the module with the latest GM software. This means no expensive trips to the dealership, no towing fees, and no paying for separate programming. This is the direct-fit, reliable repair you need to get your truck back to 100%.

Is Your GM Truck Showing These Symptoms?

A faulty BCM can cause a wide range of issues. If you’re experiencing any of the following, this module is likely the solution. This is a common failure point I’ve diagnosed on hundreds of GM trucks.

• ✔ Erratic or non-functional power windows, door locks, or mirrors.
• ✔ Interior dome lights or exterior lights staying on or not working at all.
• ✔ The security system acting up, causing a no-start condition.
• ✔ Unexplained battery drain that kills your battery overnight.
• ✔ Warning messages on the dash like “Service 4WD” or “Service StabiliTrak”.
• ✔ Diagnostic Trouble Codes (DTCs) such as U0140 (Lost Communication With Body Control Module) or other U-codes and B-codes.

A Straightforward Guide to BCM Installation

Replacing the BCM is a manageable job for a DIY enthusiast. It’s located under the driver’s side of the dashboard, near the steering column. While specific steps can vary slightly, here is a general guide:

1. Safety First: Disconnect the negative terminal from your vehicle’s battery to prevent any electrical shorts.
2. Access the Module: Remove the lower dash panel beneath the steering wheel. This usually involves a few screws or clips.
3. Locate the BCM: Identify the Body Control Module. It’s a plastic box with several large multi-pin electrical connectors plugged into it.
4. Disconnect and Remove: Carefully unplug all electrical connectors. They have locking tabs that need to be depressed. Once disconnected, unbolt or unclip the old BCM and remove it from its mounting bracket.
5. Install the New BCM: Mount your new, pre-programmed BCM in the same location. Reconnect all electrical connectors firmly until they click into place.
6. Final Steps: Reinstall the lower dash panel and reconnect the negative battery terminal.

Important Post-Installation Information

Because this module is central to many systems, a couple of simple relearn procedures may be required after installation. This is normal and ensures all related components communicate correctly with the new BCM.

• Airbag System Sync: If the airbag light is on after installation, a “Setup SDM Primary Key in BCM” procedure is needed. This requires a professional-grade scan tool to sync the airbag system with the new BCM.
• Brake Pedal Position Relearn: Some models may require a brake pedal position sensor relearn to ensure proper brake light and traction control operation.

Verified Fitment for Your GM Truck or SUV

This module is a guaranteed fit for a wide range of General Motors vehicles. Please verify your model and year from the list below. This part directly replaces part numbers 22737275, 22846365, and 22846364.
