Restore Your Camaro’s Electrical System with a Hassle-Free Solution
Is your 2012-2014 Camaro suffering from baffling electrical issues? Flickering lights, malfunctioning power windows, a dead instrument cluster, or random security system alerts are classic signs of a failing Body Control Module (BCM). As the central nervous system for your car’s body electronics, a faulty BCM can cause a cascade of frustrating and unpredictable problems. Instead of facing a costly trip to the dealership for a new module and programming fees, our plug-and-play solution gets you back on the road quickly and affordably.
This service provides a fully tested, replacement BCM programmed with your vehicle’s exact data. We transfer all the critical information—including VIN, mileage, and key data—from your original module to this replacement unit. The result is a seamless, plug-and-play installation that eliminates the need for expensive scan tools or dealership intervention. Simply send us your old BCM, and we’ll ship back a ready-to-install module, typically within one business day of receiving yours.
A Technician’s Notebook: The Camaro with a Mind of Its Own
A few months back, a 2013 Camaro rolled into my bay with a list of symptoms that sounded like something out of a horror movie. The owner said the radio would change stations on its own, the interior lights would pulse randomly, and occasionally, the car wouldn’t recognize the key fob. He’d already replaced the battery and checked all the fuses. After connecting my diagnostic tool, I found a slew of communication error codes pointing towards the BCM. These modules are notorious for internal solder joint failures, causing intermittent connections that create precisely this kind of chaos. By providing a cloned BCM, we restored all functions perfectly without the high cost and scheduling headache of a dealership visit. The customer was thrilled to have his car back to normal.
Common Signs of a Failing BCM
- âś” Unpredictable power window or door lock operation.
- âś” Horn honking or alarm sounding without reason.
- âś” Instrument panel gauges or lights working intermittently or not at all.
- âś” “Service Theft Deterrent System” or other warning messages on the dash.
- âś” Communication error codes with other modules (e.g., U0140 – Lost Communication With Body Control Module).
- âś” Headlights, taillights, or interior lights staying on or not turning on.
- âś” Engine cranks but won’t start due to security system issues.
A Straightforward Guide to Installation
Installing your programmed 2012-2014 Camaro BCM is a simple process that most DIYers can handle with basic tools. Follow these steps for a smooth replacement.
- Safety First: Always disconnect the negative terminal from your vehicle’s battery before starting any electrical work.
- Locate the BCM: In the 2012-2014 Camaro, the BCM is typically located behind the dashboard on the passenger side. You may need to remove the glove box or a lower dash panel for access.
- Disconnect and Remove: Carefully unplug the electrical connectors from the old BCM. They have locking tabs that need to be depressed. Once disconnected, unbolt or unclip the module from its mounting bracket and remove it from the vehicle.
- Install the New Module: Mount your new, programmed BCM in the same location and securely reconnect all the electrical connectors. Ensure they click into place.
- Reconnect Power: Re-install any panels you removed and then reconnect the negative battery terminal.
- Verify Operation: Start the vehicle and test all related functions: lights, locks, windows, radio, and instrument cluster to confirm the repair is complete.
Important Post-Installation Notes
While our cloning service makes this a true plug-and-play repair, some GM vehicles may require a simple relearn procedure after installation. Please be aware of the following possibilities:
- Airbag System Sync: If the airbag warning light is illuminated after installation, a ‘Setup SDM Primary Key in BCM’ procedure must be performed with a professional scan tool to sync the modules. This is only necessary if the light appears.
- Brake Pedal Position Relearn: On some models, a brake pedal position sensor recalibration might be needed to ensure correct brake light and traction control functionality.
Disclaimer: Always consult a factory service manual for your specific vehicle. No core charge is required; you can keep your original module.
Verified Vehicle Compatibility
This BCM, part number 13580696, is a direct replacement for several part numbers and fits a range of GM vehicles. Please verify your original part number is on this list: 13580696, 123589093, 13588446, 13584692, 13583542.
- Chevrolet Camaro: 2012, 2013, 2014 (Coupe, RH dash)
- Chevrolet Equinox: 2012 (LH side dash)
- Chevrolet Spark: 2013 (Left lower A-pillar)
- Chevrolet Volt: 2012 (RH engine compartment)
- Buick LaCrosse: 2012, 2013 (LH kick panel, ID 13580696)
- Buick Regal: 2012 (LH dash)
- Buick Verano: 2012 (Below center of dash)
- Cadillac SRX: 2012 (LH dash, ID 13580696)
- GMC Terrain: 2012 (LH side dash)
Frequently Asked Questions
How does the programming service work?
After you purchase, we will contact you with instructions to ship your original BCM to us. Once we receive it, we clone the data to a replacement module and ship it back to you, ready for installation.
Is this really plug-and-play?
Yes, in over 95% of cases. Because we clone your original data, the car recognizes the new module as its own, eliminating the need for dealership programming. In rare cases, a minor relearn procedure like for the airbag or brake pedal sensor may be needed.
What is the turnaround time?
We program and ship your replacement BCM within one business day of receiving your original module. We’ll send you tracking information as soon as it’s on its way back to you.
Do I need to send my keys?
No. All the necessary security and key information is stored within the BCM itself. We only need your original module to perform the cloning service.
Will this fix my specific problem?
This part resolves issues directly caused by a faulty BCM, such as erratic lights, locks, and security system faults. If you have confirmed the BCM is the problem through diagnosis, this is the most effective solution.
What if my original BCM is completely dead or missing?
If your BCM is non-communicative or lost, we may still be able to help. Please contact us directly with your vehicle’s VIN to discuss programming options before you order.
