Is Your Cadillac SRX Shifting Erratically?
If you’re experiencing harsh shifting, delayed gear engagement, or seeing transmission-related warning lights on the dash of your 2007-2009 Cadillac SRX, a failing Transmission Control Module (TCM) is a very likely culprit. The TCM is the electronic brain of your automatic transmission, responsible for orchestrating precise, smooth shifts based on data from various sensors. When it begins to fail, it can cause a host of drivability issues that can be frustrating and even unsafe.
Don’t let a faulty module keep your luxury SUV sidelined. This is a direct-fit replacement Transmission Control Module, part number 24235224, also compatible with 24239785 and YLMU. The critical difference with our service is that we program the module specifically to your vehicle’s Vehicle Identification Number (VIN) before it ships. This means it arrives ready for installation, loaded with the latest GM software updates to ensure optimal performance and longevity, eliminating the need for an expensive trip to the dealership for programming.
From the Diagnostic Bay
We had a 2008 Cadillac SRX come into the shop with the classic symptoms: the transmission was stuck in ‘limp mode’ (3rd gear only), and the check engine light was on with codes P0752 (Shift Solenoid ‘A’ Stuck On) and U0101 (Lost Communication with TCM). The customer had already replaced the solenoid pack, but the problem persisted. After confirming power and ground at the TCM connector were good, we knew the module itself was the issue. A common mistake is to just swap in a used module, but that never works due to the VIN-specific security programming. We installed one of our pre-programmed modules, performed a quick throttle body relearn, and the vehicle was shifting perfectly again. Programming it beforehand saved the customer hundreds in dealership fees and got them back on the road the same day.
Common Symptoms of a Failing SRX Transmission Control Module
- ✔ Check Engine Light or other warning lamps illuminated
- ✔ Transmission stuck in one gear (limp mode)
- ✔ Harsh, jerky, or delayed shifting between gears
- ✔ Inability to shift into certain gears
- ✔ False neutral, where the engine revs but the vehicle doesn’t move
- ✔ Diagnostic trouble codes (DTCs) related to solenoids, sensors, or communication errors (e.g., P0700, U0101)
- ✔ Poor fuel economy due to inefficient shifting
The Plug-and-Play Solution for Your Cadillac
The complexity of modern vehicle electronics can make transmission repairs daunting. This pre-programmed SRX Transmission Control Module removes the biggest hurdle: the software. By providing us with your VIN during checkout, you receive a unit that is a true plug-and-play solution. Our technicians use GM-certified equipment to flash the module with the most current software available, which often corrects factory flaws and improves transmission behavior.
This module is located in the right-hand front of the engine compartment on the SRX, making it accessible for a competent DIY mechanic or any professional repair shop. Replacing the module is a matter of disconnecting the battery, unplugging the electrical connectors, unbolting the old unit, and installing the new one. Once installed, the vehicle’s computer systems will recognize the new, correctly programmed module, restoring proper communication and function to your transmission.
Broad GM Compatibility
While this is a primary solution for the 2007-2009 Cadillac SRX, this versatile module also fits a range of other GM vehicles. Please verify your part number and application. This unit is a direct replacement for the following applications:
- Cadillac STS (2007): Transmission
- Cadillac STS (2010-2011): Transfer Case (RH dash)
- Cadillac CTS (2010): Transfer Case (RH dash), for IDs 2423522, YLMU, or 24239785
- Pontiac Solstice (2006-2010): Transmission (LH front frame rail)
- Saturn Sky (2007-2010): Transmission (LH front frame rail)
Frequently Asked Questions
Do I need to do any programming after I install this module?
No. We program the module to your vehicle’s specific VIN before we ship it. It arrives ready for installation. In some cases, a simple idle or throttle relearn procedure may be beneficial, but no special scan tools are required.
Where do I provide my VIN?
You can add your 17-digit VIN in the notes section during checkout or send it to us in a message after you place your order. We cannot ship the part until we have your VIN to ensure correct programming.
Is this a new or used part?
This is a high-quality, inspected replacement part that has been tested and loaded with fresh, vehicle-specific software from GM. It is guaranteed to restore the function of your original module.
What if my original part number is slightly different?
This module, 24239785, is a compatible replacement for part numbers 24235224 and YLMU. As long as your vehicle is listed in the compatibility chart and you have one of these part numbers, this unit will work once programmed to your VIN.
What is the warranty on this TCM?
This part comes with a standard warranty that covers defects in the module itself. Please refer to the warranty tab on the product page for specific terms and duration. Proper diagnosis is key, as the warranty does not cover issues caused by other vehicle faults.
